Wireless Hay Monitoring

HAYTECH is the single solution for preventing hay fires and improving hay quality

Your farm is at risk of burning down

Thousands of hay fires are recorded every year. Fermentation can cause bale temperatures to rise to dangerous levels in less than 24 hours.

Are you doing enough to protect your farm?

Hay fires cost farmers hundreds of thousands of dollars through lost revenues and replacement of buildings and feed. Join the cautious farmers who have already trusted monitoring to HAYTECH, the wireless solution that guards your hay 24/7.

Introducing HAYTECH

HAYTECH is a wireless monitoring system for your hay. The handy probes are connected to the internet, allowing you to follow the real-time temperature of your hay effortlessly.

Keeping your farm safe

You can check the temperature of your hay whenever you want through the free Quanturi online service. You will also receive alert messages to your phone if temperatures rise to unsafe levels.

Control hay quality

Rising temperatures can have catastrophic effects to hay quality, but with HAYTECH you can always be sure you are selling top quality hay and reduce the likelihood of product damage.

HAYTECH temperature probes

The Quanturi hay monitoring system contains easy to spot and robust HAYTECH probes. With a spike length of 40 cm, they were designed for use with square or round bales. The starter system contains 10 HAYTECH probes, but depending on the size of the farm, a single HAYTECH system can contain up to 500 probes.

Base station & repeater

The HAYTECH probes communicate with a base station and an optional repeater. The base station transmits the temperature measurements to the Cloud from which you can check the temperatures at any time. The repeater is an extra security device to guarantee the good signal transmission between the probes to the base station if signal strength is weak in a large shed.

Farmscan Solar 3G/4G Base

Farmscan has a purpose built 3G/4G solar base station to connect to the HAYTECH base station. If your hay shed does not have access to 240v - you will need to purchase our solar setup or provide your own.

The Farmscan Base is available in 2 options:

• NB IoT 3G/4G - Telstra SIM - owned by Farmscan - 12month subscription

• 3G/4G Wi-Fi - End user supplies SIM card on either Telstra or Optus. This Wi-Fi router can also provide a HOTSPOT for use with security cameras or other Wi-Fi enabled devices.

If you are unsure of the options you require, please give us a call on 1300 327 672.

Each Farmscan Solar base comes with a 20w Solar Panel, 12v 12A SLA battery, 30m of solar panel power cable and 20m each of power & data cable to the base station.

Install in
3 easy steps

The probes of the HAYTECH system measure the hay temperature and you can see the temperature status on the www.Quanturi.app monitoring application. In case of any overheating, you will receive SMS warning and alert messages on your mobile phone.
NB The system requires an Internet connection to Quanuri Cloud Server

1. Install the system

See all the sensors on one glance. The Sensors are displayed with their ID and the latest measurement with timestamp. Hottest sensors are displayed on top by default. You can change the order by clicking on the column titles.

2. Place your probes

Place the wireless probes in the bales you want to monitor.

3. Don't worry

That's it. You can check on your hay whenever you want from your phone, tablet or computer. If temperatures start rising, you will receive an SMS alert.

The HAYTECH probes

Each HAYTECH probe measures the hay temperature regularly every hour. The Repeater unit which is located inside or nearby the hay storage, collects the measurement data and transmits it wirelessly to your HAYTECH base station. The base station forwards the data to the secure www.Quanturi.app server, which sends possible warning and alert messages to your phone and displays the temperature status on www.Quanturi.app.

The safest plan is to place one in each bale.Every additional sensor probe improves situation awareness. However, even monitoring a portion of the haystack will increase security compared to manual temperature sampling.

Standard
base station

The standard base station is connected to the internet via an ethernet cable. It is suitable for indoor use only and should be placed in your office or home, not further than 200m form the hay storage.

The repeater collects the data from the probes in the storage and passes it on to the standard base station.

3G/4G
base station

The 3G/4G base station contains a Sim-card (Choice of Telstra/Optus) and is able to communicate directly via the mobile network with the Quanturi secure cloud. You can install this base station anywhere there is no fixed internet connection. A repeater can be used to cover a second hay storage on the same property. NB. The 3G/4G base station requires a 240v power connection or you may chose to purchase our additional solar base station.

Quanturi "FREE"

www.Quanturi.app is our web service for visualising the measurement data from the wireless probes. Here you will access an instant overview over all your HAYTECH probes and will be able to set the alert levels that will trigger the SMS alarms. Quanturi FREE includes the web interface and the SMS alarms - all for free!

Quanturi "PREMIUM"

PREMIUM is an affordable service plan that allows you to follow the temperature history of your probes, change the display name of each probe, make notes and place your probes in a handy virtual storage locator to find them easier in case of danger.

HAYTECH
service plans

Tracking your hay at www.quanturi.app gives you more clarity and accountability so you can make great quality hay and prevent fires. To get the best results you need the power of Quanturi PREMIUM features.

FREE

Every kit comes with this

  • Sensor list
  • Adjustable alert levels
  • 1x Assistant phone numbers (SMS)

PREMIUM

Upgrade for 99 Euro (Under AUD$200)

  • Sensor list
  • Adjustable alert levels
  • 3x Assistant phone numbers (SMS)
  • Temperature history
  • Probe naming
  • Storage locator

HAYTECH - Free

TEMPERATURE OVERVIEW

See all the sensors on one glance. The Sensors are displayed with their ID and the latest measurement with timestamp. Hottest sensors are displayed on top by default. You can change the order by clicking on the column titles.

ALERT LEVELS

Customize the temperature limits for dispatching the warning and alert messages.

ALERT SMS

See all the sensors on one glance. The Sensors are displayed with their ID and the latest measurement with timestamp. Hottest sensors are displayed on top by default. You can change the order by clicking on the column titles.

HAYTECH - Premium

TEMPERATURE HISTORY

View the measurement data in a graph. It’s important to know the history of the hay you produce to regulate and proof quality. You can display the history for the time period of one day, one week or one month.

STORAGE LOCATOR

Record the sensor positions with the Storage locator while stacking the bales. If you get a heat alert, you can easily locate the overheated bale from the stack for further protective actions.

How HAYTECH works

Install Gallery

Order Now

This All-in-one HAYTECH package Includes:

  • 20x wireless HAYTECH probes.
  • Wireless Base Station device to communitcate with the HAYTECH probes
    • 20m of data & power cable included for shed mounting
  • Quanturi FREE online service that includes alert messaging and visualization.
    • Premium version available through the website
  • 3G/4G Wi-Fi enabled modem (SIM starter of Telstra or Optus included)
    • SIM cards provided are Pre Paid - Charge as you go
    • You may also BYO SIM card
  • Solar Kit with 20w solar panel & 12Ah backup battery
    • Includes 30m of cable for roof mounting of solar panel
  • 240v wall charger if a power point is availabe in the shed

An optional repeater is also available if probe signals are too far away from base unit when located in hay shed.

The HAYTECH kit is ready to go! - Simply add additional probe packs for monitoring of more bales.

$5,250.00

To extend your HAYTECH system, simply add packs of 10 probes to your existing base station.

How many probes are needed?

The safest plan is to place one in each bale. However, even monitoring a portion of the haystack will increase security compared to manual temperature sampling.

NB : AU Configuration

$1,450.00

PRICES DISPLAYED ARE EXCLUDING GST
