Smarter Boom Control for Precision Spraying

Our ISOBUS Spray solution is designed for maximum accuracy in boom spraying applications. It supports advanced section control and compatibility with electric and hydraulic pumps, while managing up to 256 sections and multiple tanks. With intuitive ICON displays and support for multiple booms, this solution is ideal for OEMs seeking precision and reliability across various crops and terrains.

NOW WITH MULTI-LINE

As the sprayer speeds up and covers more area per ha, flow must also increase to maintain the desired application rate. Each nozzle has a defined flow capacity. When that capacity is exceeded, the system can no longer maintain the required application rate using that nozzle line alone.

A multi-line system can identify when a nozzle line is approaching this point and automatically switch to another line fitted with higher-flow nozzles. Once the capacity of individual lines has been exceeded, the system can activate a combination of lines. This continues until all available lines are operating simultaneously to provide the maximum achievable flow capacity.

Precision & Reliability

Powerful Boom Control for Modern Agriculture

This system brings together precise control and flexibility for self-propelled, trailed, and mounted sprayers. It supports full section control, individual nozzle control, and up to three boom systems with multiple products. Built on full ISOBUS compatibility, it works seamlessly with TC-BAS, TC-GEO, and TC-SC to deliver consistent control and application performance.

The system is designed for easy use and fast setup. With AUX-N support for tactile control and compatibility with SmartAG/Farmscan’s ICON displays, operators can work efficiently in real-time with clear visual feedback and simplified boom management.

Part of the Extended Connected Suite

The ISOBUS Spray solution integrates into SmartAG’s connected platform. Features like wireless updates and remote calibration through theWireless Calibration Module (WCM)simplify setup and servicing, while ICON display units provide clear diagnostics and calibration feedback on the go

Backwards Compatibility

SmartAG’s ISOBUS Spray solution works with existing ECUs and SmartAG hardware, including older 7000 Series setups. Configuration files can be shared across terminals, reducing installation time and ensuring consistent performance without needing to start from scratch.

  • 256 Section Control

    Manage up to 256 sections with individual nozzle shutoff and precise boom mapping.

  • Multi Boom Compatibility

    Control up to three separate booms with individual logic and application rates.

  • Multi Tank Support

    Apply multiple products simultaneously using multiple tanks and application lines.

  • Electric or Hydraulic Pumps

    Compatible with a wide range of sprayer pump types.

  • AUX-N Tactile Control

    Use the ISOBUS switchbox or external controls for ergonomic and in-field adjustments.

1 5

Your Complete ISOBUS Solutions

  • ISOBUS Spray

    Our ISOBUS spray solution supports full section control, individual nozzle shutoff, and multi-boom compatibility to manage up to 256 sections with precision.

  • ISOBUS Spread

    This system enables accurate calibration and gate control for gravity-fed spreaders, with live load cell feedback and automated headland shutoff.

  • ISOBUS Seed

    SmartAG’s ISOBUS seed controller manages up to six products with variable rate, section shutoff, blockage sensing, and dynamic depth control.
